Mira Advance ATL Thermostatic Shower: A Comprehensive Guide
This guide details the Mira Advance ATL, a thermostatic shower offering safe, reliable performance. Installation and user manuals are readily available online for all models.
The Mira Advance ATL Thermostatic Shower represents a significant advancement in home showering technology, designed to deliver a consistently comfortable and safe experience. This electric shower, available in 9.0 and 9.8kW models, is particularly noted for its precise thermostatic control, ensuring water temperature remains stable even with fluctuations in mains water pressure.
Understanding the Mira Advance ATL begins with recognizing its suitability for mains-fed cold water systems. Detailed installation and user manuals, easily accessible online, guide users through setup and operation. These resources cover everything from pre-installation checks to troubleshooting common issues. The shower’s adjustable temperature limit adds an extra layer of safety, preventing scalding. Whether you have a standard, extra, or Flex extra model, this shower prioritizes user well-being and convenience.
Key Features and Benefits
The Mira Advance ATL boasts several key features enhancing the showering experience. Its core benefit lies in the thermostatic valve, maintaining a consistent water temperature, eliminating sudden hot or cold shocks. Adjustable temperature limit functionality, detailed in the user manual, provides enhanced safety, particularly important for families.
Easy installation is another significant advantage, with comprehensive guides available online. The shower’s design incorporates a splash guard and efficient flow valve. Furthermore, the turbine and connector assembly contribute to reliable performance. Models like the Flex extra offer additional features; Ultimately, the Mira Advance ATL delivers a high-performance, safe, and user-friendly showering solution, backed by readily available support and documentation.
Understanding the Thermostatic Valve
The Mira Advance ATL utilizes a thermostatic valve to deliver consistent water temperature, detailed in the manual, ensuring comfort and safety during each shower.
How Thermostatic Technology Works
Thermostatic technology, as explained in the Mira Advance ATL manual, employs a valve containing heat-sensitive elements. These elements react to changes in water temperature, automatically adjusting the blend of hot and cold water. This precise mixing maintains a remarkably consistent temperature, regardless of fluctuations in the hot water supply – even if someone flushes a toilet or uses another water outlet.
The valve quickly responds to pressure or temperature variations, ensuring a stable and comfortable showering experience. It’s a sophisticated system designed for safety and convenience, preventing sudden hot or cold surges. The manual details how this internal mechanism operates, providing insight into its reliable performance and user-friendly design. Understanding this process highlights the Mira Advance ATL’s commitment to a safe and enjoyable shower.
Benefits of Consistent Water Temperature
The Mira Advance ATL manual emphasizes the significant benefits of its consistent water temperature. Primarily, it enhances showering comfort, eliminating unpleasant shocks from sudden temperature changes. This is particularly crucial for families with young children or elderly individuals, minimizing the risk of scalding.
Consistent temperature also contributes to water conservation; users are less likely to adjust the temperature repeatedly, reducing wasted water. Furthermore, the thermostatic control provides peace of mind, knowing the shower will maintain a safe and enjoyable temperature throughout each use. The manual highlights these advantages, showcasing the Mira Advance ATL’s focus on safety, comfort, and efficiency.
Installation Guide
Refer to the Mira Advance ATL manual for detailed installation instructions. Pre-installation checks and a step-by-step process are clearly outlined for all models.
Pre-Installation Checks
Before beginning the installation of your Mira Advance ATL, carefully review the manual. Ensure your cold water supply is mains-fed and provides adequate pressure, as specified in the manual’s technical specifications. Verify the electrical supply matches the shower’s power requirements – typically 9.0kW or 9.8kW.
Inspect the installation area for any obstructions and ensure sufficient space for access and maintenance. Confirm the shower’s location allows for proper ventilation. Critically, always turn off both the water and electrical supplies before commencing any work. The manual emphasizes the importance of electrical safety; if unsure, consult a qualified electrician. Check all components are present and undamaged, referencing the parts list within the manual.
Step-by-Step Installation Process
Following the Mira Advance ATL manual, begin by mounting the shower bracket securely to the wall, ensuring it’s level. Connect the inlet elbow and flow valve outlet, referencing the manual’s diagrams for correct orientation. Attach the turbine and connector, then carefully connect the cold water inlet.
Next, wire the shower according to the manual’s wiring instructions, paying close attention to earth connections. Securely fit the splash guard and shower unit onto the bracket. Thoroughly test all connections before restoring water and electrical supplies. The manual stresses the importance of a qualified electrician for electrical work. Double-check all seals to prevent leaks.
Connecting to Water and Electrical Supplies
The Mira Advance ATL manual emphasizes safe connection procedures. For water, connect to the mains cold water supply using appropriate plumbing fittings, ensuring compliance with regulations. The manual details correct inlet pressure requirements. Electrical connection must be carried out by a qualified electrician, adhering to wiring diagrams within the manual.
Ensure the electrical supply matches the shower’s power rating (9.0kW or 9.8kW). Proper earthing is critical for safety, as highlighted in the manual. Isolate the electrical supply before commencing any wiring. Double-check all connections for security and watertight integrity, following the manual’s guidance.
Operating the Mira Advance ATL
The manual guides users through powering on, initial setup, and temperature adjustment. Utilize the temperature limit stop for enhanced safety, as detailed in the manual.
Powering On and Initial Setup
Before your first use of the Mira Advance ATL, carefully consult the manual for crucial safety information. Ensure the electrical supply is correctly connected and switched on, adhering to all electrical safety guidelines outlined within. Upon initial power-up, the shower may take a moment to prime; this is normal.
The manual details how to perform a pre-shower check, verifying water flow and temperature control functionality. Familiarize yourself with the shower’s controls – power button, temperature adjustment, and any additional features specific to your model (Standard, Extra, or Flex Extra). It’s recommended to initially set a lower temperature and gradually increase it to your desired comfort level, always testing the water temperature before fully entering the shower.
Refer to the manual for specific instructions regarding the temperature limit stop and how to adjust it to prevent scalding.
Adjusting Water Temperature
The Mira Advance ATL’s manual emphasizes precise temperature control via the shower’s dial. Rotate the dial clockwise to increase the water temperature and counter-clockwise to decrease it. The thermostatic valve maintains a consistent temperature, minimizing fluctuations during your shower.
The manual advises starting with a lower temperature and gradually adjusting it to your preference, always testing the water before fully entering. Be mindful of the temperature limit stop; it prevents excessively hot water. If the water isn’t reaching your desired temperature, check the incoming water supply temperature and ensure sufficient water pressure.
Consult the manual for troubleshooting temperature inconsistencies and understanding the shower’s response to changes in water pressure.
Using the Temperature Limit Stop
The Mira Advance ATL manual highlights the crucial safety feature: the temperature limit stop. This adjustable mechanism prevents water from exceeding a pre-set maximum temperature, safeguarding against scalding. Located on the shower unit, it’s typically adjusted using a small tool or screwdriver, as detailed in the manual.
The manual recommends setting a comfortable maximum temperature, especially when children or vulnerable individuals use the shower. Regularly check the limit stop’s setting to ensure it remains appropriate. Adjusting it involves loosening a screw, moving the slider to the desired temperature, and re-tightening the screw.
Always refer to the manual for specific instructions and diagrams related to your ATL model.
Troubleshooting Common Issues
The Mira Advance ATL manual suggests resetting the unit by cutting power. For persistent problems, like cold/hot water, contact Mira customer support immediately.
Low Water Pressure Problems
If experiencing low water pressure with your Mira Advance ATL, consult the official manual first. Check that the inlet filter isn’t blocked, as debris can significantly reduce flow. Ensure the shower is connected to a mains-fed cold water system with adequate pressure – the manual specifies the required range.
Verify that other taps in your home aren’t simultaneously drawing large amounts of water, which could lower pressure to the shower. A partially open stop valve on the shower’s inlet pipe can also restrict flow. If the problem persists after these checks, the pump (for low-pressure models) might be malfunctioning, requiring professional attention. Always refer to the manual for specific troubleshooting steps related to your model.
Temperature Fluctuations
Temperature instability in your Mira Advance ATL often indicates issues with the thermostatic valve. The manual advises checking for limescale buildup, as this disrupts accurate temperature regulation. Descaling the valve, as detailed in the maintenance section of the manual, is crucial.
Fluctuations can also occur if the temperature limit stop is set too close to the desired temperature; adjust it slightly. Ensure consistent cold water supply – simultaneous use of other hot water appliances can cause dips. If problems continue, the thermostatic cartridge itself might be faulty, necessitating replacement. Always consult the manual before attempting any repairs, and prioritize safety.
Shower Not Turning On
If your Mira Advance ATL fails to power on, the manual suggests first verifying the electrical supply. Check the circuit breaker hasn’t tripped and that the shower’s power cable is securely connected. A complete reset – switching off the electrics for 30 minutes – is recommended, as outlined in troubleshooting guides within the manual.
Inspect the shower’s internal fuse; a blown fuse will prevent operation. If these steps don’t resolve the issue, the problem may lie within the shower’s control unit. Contacting Mira customer support, as detailed in the manual’s warranty section, is advised for more complex issues or potential repairs.
Maintenance and Care
Regular cleaning of the showerhead and descaling the thermostatic valve, per the manual, ensures optimal performance. Inspect components routinely for wear.
Cleaning the Shower Head
Maintaining a clean shower head is crucial for consistent water flow and a pleasant showering experience with your Mira Advance ATL. Over time, limescale and mineral deposits can build up, restricting water pressure and potentially damaging the shower head itself. The manual recommends regular cleaning, ideally monthly, depending on water hardness.
To clean, gently remove the shower head (consult the manual for specific instructions for your model). Soak it in a solution of white vinegar and water – a 50/50 mix is effective – for at least 30 minutes, or even overnight for stubborn deposits. Use a soft brush, like an old toothbrush, to scrub away any remaining limescale. Rinse thoroughly with clean water before reattaching. Avoid abrasive cleaners, as these can scratch the surface and damage the finish.
Regular cleaning will prolong the life of your shower head and ensure optimal performance.
Descaling the Thermostatic Valve
Descaling the Mira Advance ATL’s thermostatic valve is vital for maintaining accurate temperature control and preventing malfunctions. Limescale buildup can impede the valve’s operation, leading to inconsistent water temperatures or even complete failure. The manual advises descaling frequency based on water hardness – more often in hard water areas.
Refer to your manual for specific descaling instructions, as procedures vary slightly between models. Generally, this involves isolating the water supply, partially disassembling the valve (following the manual’s guidance precisely), and flushing it with a descaling solution. A commercially available descaler designed for showers is recommended.
Thoroughly rinse the valve with clean water after descaling to remove all traces of the solution before reassembling and restoring the water supply.
Regular Inspection of Components
The Mira Advance ATL manual stresses the importance of routine component checks for longevity and safety. Regularly inspect the shower head for limescale buildup and blockages, cleaning as needed. Examine the hose for kinks, cracks, or leaks, replacing it if damaged.
Crucially, check the thermostatic valve for any signs of corrosion or wear. Ensure all connections are tight and free from leaks. The manual details how to access and inspect key components. Pay attention to the turbine and connector assembly, as highlighted in installation guides.
Proactive inspection, guided by the manual, can identify potential issues before they escalate, saving on repair costs and ensuring continued safe operation.
Safety Precautions
The Mira Advance ATL manual warns of scalding risks; adjust temperature limits carefully. Electrical safety and correct water pressure are vital for safe operation.
Electrical Safety Guidelines
The Mira Advance ATL manual emphasizes crucial electrical safety precautions. Installation must be performed by a qualified electrician, adhering to current regulations. Always isolate the shower’s electrical supply at the consumer unit before any maintenance or inspection.
Ensure the shower is correctly earthed to prevent electric shock. Never attempt to repair electrical components yourself; contact Mira customer service for assistance. The manual details specific power requirements – 9.0kW or 9.8kW – and warns against overloading the electrical circuit.
Avoid water contact with electrical parts. Regularly check for any signs of damage to the cable or connections. Following these guidelines ensures safe operation and prevents potential hazards. Ignoring these warnings could lead to serious injury or fire.
Water Pressure Considerations
The Mira Advance ATL manual highlights the importance of suitable water pressure for optimal performance. This shower is designed for mains-fed cold water systems, requiring adequate pressure to function correctly. Low water pressure can result in reduced flow or inconsistent temperature.
The manual specifies a recommended water pressure range; exceeding this range may damage the thermostatic valve. It’s crucial to check your home’s water pressure before installation. If pressure is too low, a pump may be necessary.
Ensure the inlet filter is clean to prevent debris from restricting water flow. Consistent water pressure is vital for maintaining the shower’s thermostatic control and delivering a comfortable showering experience. Refer to the manual for detailed guidance.
Scald Prevention Measures
The Mira Advance ATL manual strongly emphasizes scald prevention due to its ability to deliver high temperatures. A key feature is the adjustable temperature limit stop, allowing users to pre-set a maximum temperature. Always set this limit to a safe level, particularly when children or vulnerable individuals are present.
The thermostatic valve rapidly adjusts to maintain the set temperature, minimizing fluctuations. However, it’s vital to test the water temperature before showering, especially after installation or adjustments.
The manual warns against removing or adjusting safety features. Regular checks ensure the temperature limit stop functions correctly. Following these precautions significantly reduces the risk of accidental scalding.
Technical Specifications
The Mira Advance ATL manual details power requirements of 9.0kW or 9.8kW, a water pressure range, and specific dimensions and weight for each model.
Power Requirements
The Mira Advance ATL Thermostatic Shower, as detailed in its manual, is available in two primary power configurations: 9.0kW and 9.8kW. Selecting the appropriate power rating is crucial for optimal performance and compatibility with your existing electrical system.
The manual emphasizes the importance of a qualified electrician performing the installation to ensure adherence to all relevant safety regulations and building codes. Incorrect wiring or an inadequate electrical supply can lead to malfunction or, more seriously, pose a safety hazard.
Before installation, verify your home’s electrical capacity can support the chosen shower model. The manual provides clear guidance on minimum cable sizes and recommended fuse ratings for both 9.0kW and 9.8kW versions, ensuring safe and efficient operation.
Water Pressure Range
The Mira Advance ATL Thermostatic Shower’s manual specifies a minimum static water pressure of 1.0 bar (14.5 psi) for optimal performance. However, it’s designed to operate effectively within a broader range, up to a maximum of 5.0 bar (72.5 psi).
The manual highlights that pressures outside this range may affect the shower’s functionality, potentially leading to reduced flow or inconsistent temperature control. It’s crucial to assess your home’s water pressure before installation.
If your water pressure is consistently below 1.0 bar, a pump may be required to boost the flow. The manual details compatibility with various pump systems. Conversely, excessively high pressure may necessitate a pressure-reducing valve to protect the shower and plumbing.
Dimensions and Weight
The Mira Advance ATL Thermostatic Shower manual provides detailed physical specifications for installation planning. The shower unit itself typically measures approximately 180mm in width, 105mm in height, and projects around 120mm from the wall. These dimensions can vary slightly depending on the specific model – standard, extra, or Flex extra.
Regarding weight, the manual indicates the unit weighs approximately 3.2 kg. This is an important consideration when mounting the shower to ensure adequate wall support. The packaging, including all components, will naturally weigh more.
Detailed diagrams within the manual illustrate these dimensions clearly, aiding in accurate placement and avoiding potential obstructions during installation.
Mira Advance ATL Models Comparison
The Mira Advance ATL manual details standard, extra, and Flex extra models. Flex Extra boasts enhanced features, offering greater flexibility and control over your showering experience.
Standard vs. Extra Models
The Mira Advance ATL manual clearly outlines the distinctions between the standard and extra models. Both provide consistent thermostatic temperature control, ensuring a safe and comfortable showering experience. However, the ‘Extra’ model incorporates several enhancements. These include a more robust pump for improved performance, particularly in low-pressure water systems.
Furthermore, the Extra model often features a larger showerhead, delivering a more immersive and luxurious spray. The manual highlights that the Extra model is designed for homes with varying water pressure, offering greater reliability. While the standard model is perfectly adequate for many installations, the Extra provides a premium experience and increased peace of mind, especially where water pressure is a concern. Refer to the manual for detailed specifications of each model.
Flex Extra Model Features
The Mira Advance ATL manual details the ‘Flex Extra’ as the premium offering, building upon the ‘Extra’ model’s enhancements. A key feature is its adjustable temperature limit, allowing users to pre-set a maximum temperature for added safety, particularly beneficial for families with children or vulnerable individuals. The manual emphasizes the Flex Extra’s improved pump performance, ensuring consistent water pressure even during peak usage.
Additionally, the Flex Extra often includes a convenient pause function, conserving water while showering. The manual illustrates how to utilize this feature effectively. It also boasts a more durable and aesthetically pleasing chrome finish. For those seeking the ultimate showering experience with enhanced control and reliability, the Flex Extra, as described in the manual, is the ideal choice.
Customer Support and Warranty Information
The Mira manual provides contact details for customer service and outlines warranty coverage, ensuring support for your Advance ATL thermostatic shower.
Contacting Mira Customer Service
Mira offers comprehensive customer support for the Advance ATL thermostatic shower. Accessing assistance is straightforward, with multiple channels available to address your queries. The official Mira website is a primary resource, often featuring a detailed FAQ section and downloadable versions of the manual.
For direct assistance, you can contact Mira customer service via telephone. Their dedicated team is equipped to handle technical questions, installation concerns, and warranty claims. Furthermore, Mira provides support through email, allowing you to submit detailed inquiries and receive prompt responses.
When contacting support, having your shower model number and date of purchase readily available will expedite the process. Referencing the manual can also help you articulate your issue clearly. Mira is committed to providing excellent customer care and ensuring your satisfaction with your shower system.
Warranty Coverage Details
Mira Advance ATL thermostatic showers are backed by a manufacturer’s warranty, providing peace of mind. The standard warranty period typically covers defects in materials and workmanship for a specified duration from the date of purchase. Carefully reviewing the manual is crucial to understand the specific terms and conditions.
Warranty coverage generally includes repair or replacement of faulty components. However, it typically excludes damage resulting from improper installation, misuse, or lack of regular maintenance as outlined in the manual. Proof of purchase is essential for any warranty claim.
Mira may require the return of defective parts for inspection. The warranty does not cover labor costs associated with repairs unless explicitly stated. Registering your shower online can streamline the warranty claim process. Full details are available in the product manual and on the Mira website.
